Akai MPC Live User Manual

392
MPC Studio mk2
Pads
(16) velocity- and pressure-sensitive pads, RGB-backlit
(8) banks accessible via Pad Bank buttons
Knobs
(1) 360° push encoder for display navigation and selection
Touch Strip
(1) multi-function 5.5" (140 mm) touch-capacitive controller with LED indicators
Buttons
(39) LED backlit dedicated function buttons
Display
Full-color LCD
Connections
(1) 1/8" (3.5 mm) MIDI input
(1) 1/8" (3.5 mm) MIDI output
(1) USB Type-B port
Power
via USB
Dimensions
(width x depth x height)
12.0” x 6.7” x 1.5”
305 x 171 x 37 mm
Weight
1.8 lbs.
0.83 kg

Akai MPC Live Specifications

General

Built-in display	Yes
Mixer section	-
Product color	Black
Number of drum pads	16
Built-in optical drive	No
USB version	3.2 Gen 1 (3.1 Gen 1)
Audio (L/R) out	2
Headphone outputs	1
USB connector type	USB Type-A, USB Type-B
USB ports quantity	3
Headphone connectivity	3.5 mm
Cables included	USB

Weight and Dimensions

Depth	223 mm
Width	410 mm
Height	67.5 mm
Weight	2721.55 g
