Mode Selection Shortcut
You can now press and hold the Menu button on your MPC hardware and press a pad to select a menu mode. The
pads follow the 4x4 layout of the Mode Menu.
Pad Perform Mode: Chromatic Type
You can now use Pad Perform Mode to set the pads to follow a chromatic layout. When the Chromatic type is
selected, each pad is assigned a note, ascending by one semitone with each pad. Pads with notes in the key
determined by the Scale will be lit, while pads with notes between the scale degrees will be unlit.
Q-Link Navigation Enhancements
Q-Link functionality has been enhanced in the following modes: Main Mode, Track View, Next Sequence, Grid Editor,
and Audio Edit Mode.
Set the Q-Link Mode to Screen in these pages to access the following controls:
Use Q-Link Knob 2 to adjust the playhead position.
Use Q-Link Knob 3 to scroll through the waveform in the large waveform display.
Use Q-Link Knob 4 to zoom in or zoom out at the playhead position.
Note: For MPC hardware in standalone mode, the Zoom and Scroll Q-Links are only available in the Grid Editor and
Audio Edit Mode.

Akai MPC Live Specifications

General

Built-in display	Yes
Mixer section	-
Product color	Black
Number of drum pads	16
Built-in optical drive	No
USB version	3.2 Gen 1 (3.1 Gen 1)
Audio (L/R) out	2
Headphone outputs	1
USB connector type	USB Type-A, USB Type-B
USB ports quantity	3
Headphone connectivity	3.5 mm
Cables included	USB

Weight and Dimensions

Depth	223 mm
Width	410 mm
Height	67.5 mm
Weight	2721.55 g
