Akai MPC Live User Manual

79
Envelopes
To set the stages of an envelope, do either of the following:
Tip: Tap the expand-rectangle icon above the envelope to show a close-up view.
• Tap and drag a “handle” of an envelope stage in the desired direction.
• Set the numeric value of an envelope stage by adjusting or entering it as a parameter value
(described earlier).
The Envelope tab in Program Edit Mode.
Close-up of an AD-type filter envelope. Close-up of an AHDS-type amp envelope.

Akai MPC Live Specifications

General

Built-in display	Yes
Mixer section	-
Product color	Black
Number of drum pads	16
Built-in optical drive	No
USB version	3.2 Gen 1 (3.1 Gen 1)
Audio (L/R) out	2
Headphone outputs	1
USB connector type	USB Type-A, USB Type-B
USB ports quantity	3
Headphone connectivity	3.5 mm
Cables included	USB

Weight and Dimensions

Depth	223 mm
Width	410 mm
Height	67.5 mm
Weight	2721.55 g
