Akai MPC Live User Manual

385
MPC One / MPC One+
Digital Audio System ADCs
24-bit @ 44.1, 48, or 96 kHz
DACs
24-bit @ 44.1, 48, or 96 kHz
Digital Signal Processing
32-bit floating point
Line Inputs 1–2
(2) balanced 1/4”
(6.35 mm) TRS
Frequency Response
20 Hz – 20 kHz (+0/-0.8 dB)
Dynamic Range
113 dB (A-weighted)
Signal-to-Noise Ratio
111 dB (1 kHz, +4 dBu, A-weighted)
THD+N
0.002% (1 kHz, +4 dBu, -1 dBFS)
Max Input Level
+16 dBu
Sensitivity
-13.5 dBu
Gain Range
29.5 dB
Line Outputs 1–2
(2) balanced 1/4”
(6.35 mm) TRS
Frequency Response
20 Hz – 20 kHz (+0/-0.8 dB)
Dynamic Range
113 dB (A-weighted)
THD+N
0.003% (1 kHz, -1 dBFS)
Maximum Output Level
+9 dBu
Output Impedance
100 Ω
Headphone Output
(1) 1/8” (3.5 mm)
stereo headphone
Frequency Response
20 Hz – 20 kHz (+0/-0.8 dB)
Dynamic Range
112.5 dB (A-weighted, 32Ω)
THD+N
0.006% (1 kHz, -1 dBFS, 32Ω)
Maximum Output Level
28.8 mW @ 32Ω
Mechanical Pads
(16) velocity- and pressure-sensitive pads, RGB-backlit
(8) banks accessible via Pad Bank buttons
Knobs
(4) 360° touch-sensitive Q-Link Knobs
(4) Q-Link Knob columns accessible via Q-Link button
(1) 360° encoder for display navigation and selection via
push
Buttons
(31) dedicated function buttons; red-, amber-, or green-
backlit
Display
7.0” / 177 mm (diagonal)
5.9” x 3.7” / 151 x 94 mm (width x height)
Full-color LED-backlit display with touch interface
CPU Processor: Quad-core ARM
®
processor
RAM: 2 GB
Storage: 2 GB user storage, 2 GB pre-installed content (MPC One)
16 GB internal stora
g
e, 7.8 GB user stora
g
e (MPC One+)

Akai MPC Live Specifications

General

Built-in display	Yes
Mixer section	-
Product color	Black
Number of drum pads	16
Built-in optical drive	No
USB version	3.2 Gen 1 (3.1 Gen 1)
Audio (L/R) out	2
Headphone outputs	1
USB connector type	USB Type-A, USB Type-B
USB ports quantity	3
Headphone connectivity	3.5 mm
Cables included	USB

Weight and Dimensions

Depth	223 mm
Width	410 mm
Height	67.5 mm
Weight	2721.55 g
