295
Send Levels (audio tracks, programs, and submixes only)
When the Send tab is selected, use the data dial or –/+ buttons to adjust the send level of audio tracks,
programs, or submixes.
The level sliders in each pad show a visual representation of the level. Double-tap a pad on the screen to open a
large version of the level slider.
You can use up to four send channels. Tap Send to cycle through the four available slots for each.
To learn how to use send effects, please see General Features > Effects > Send/Return Effects.
Important: When using send channels, make sure you have already loaded at least one effect to it using the
return mixer. See Returns below to learn how to do this.
Insert Effects (audio tracks, programs, returns, submixes, and main outputs only)
When the Insert tab is selected, use the data dial or –/+ buttons to open a window where you can select an
effect for the currently selected audio track, program, return, submix, or main output.
Instead of level sliders, there are fields that display 0–4 boxes to indicate which insert slots have a loaded effect.
The level meters in each pad show a visual representation of the level. Double-tap a pad on the screen to open a
large version of the level slider.
You can select up to four insert effects for each audio track, program, return, submix, or main output. Tap the
Insert button to cycle through the four available slots for each.
To learn how to use insert effects, please see General Features > Effects > Insert Effects.
Routing (audio tracks, programs, returns, and submixes only)
When the Route tab is selected, use the data dial or –/+ buttons to select the output of the currently selected
program, return, or submix.
