Akai MPC Live User Manual

383
Headphone Output
(1) 1/8” (3.5 mm)
stereo headphone
Dynamic Range
111 dB
(A-weighted)
THD+N
0.003%
(1 kHz, -1 dBFS, 10 mW/channel into 32 Ω headphones)
Frequency Response
20 Hz – 20 kHz
(+0.0 / -0.2 dB)
Maximum Power Delivered
+35 mW
(<1% THD, 32 Ω headphones)
Maximum Output Level
+10 dBu
Output Impedance
32 Ω
Pads
(16) velocity- and pressure-sensitive pads, RGB-backlit
(8) banks accessible via Pad Bank buttons
Knobs
(4) 360° touch-sensitive Q-Link Knobs
(4) Q-Link Knob columns accessible via Q-Link button
(1) 360° encoder for display navigation and selection via push
Buttons
(27) dedicated function buttons; red-, amber-, or green-backlit
Display
6.9” / 176 mm (diagonal)
5.9” x 3.7” / 150 x 93 mm (width x height)
Full-color LED-backlit display with touch interface
CPU Processor: Quad-core ARM
®
processor
RAM: 2 GB
Storage: 16 GB, expandable via SATA connections
Wi-Fi Frequency
2.4 GHz / 5 GHz
Standard
802.11a/b/g/n/ac
Max. Power
2.4 GHz Wi-Fi: +17 dBm
5 GHz Wi-Fi: +17 dBm
Bluetooth
V
ersion
4.2, 5
Profile
HID, A2DP
Connections
(2) 1/4” (6.35 mm) TRS inputs (1 stereo pair)
(6) 1/4” (6.35 mm) TRS outputs (3 stereo pairs)
(1) 1/4” (6.35 mm) stereo headphone output
(2) RCA inputs (1 stereo pair)
(2) 5-pin MIDI inputs
(2) 5-pin MIDI outputs
(4) Stereo CV/Gate outputs
(1) Ethernet link port
(2) USB Type-A ports
(1) USB Type-B port
(1) SD card slot
(1) power adapter input

Akai MPC Live Specifications

General

Built-in display	Yes
Mixer section	-
Product color	Black
Number of drum pads	16
Built-in optical drive	No
USB version	3.2 Gen 1 (3.1 Gen 1)
Audio (L/R) out	2
Headphone outputs	1
USB connector type	USB Type-A, USB Type-B
USB ports quantity	3
Headphone connectivity	3.5 mm
Cables included	USB

Weight and Dimensions

Depth	223 mm
Width	410 mm
Height	67.5 mm
Weight	2721.55 g
