Akai MPC Live User Manual

388
Outputs 3–4
(2) impedance-
balanced 1/4” (6.35
mm) TRS
Frequency Response
20 Hz – 20 kHz
(+0.03 / -0.2 dB)
Dynamic Range
115 dB
(A-weighted)
THD+N
0.004%
(1 kHz, -1 dBFS)
Maximum Output Level
+16 dBu
Output Impedance
50 Ω
Headphone Output
(1) 1/4” (6.35 mm)
stereo headphone
Frequency Response
20 Hz – 20 kHz
(+0.05 / -0.2 dB)
Dynamic Range
108 dB
(A-weighted)
THD+N
0.004%
(1 kHz, 10 mW per channel into 32 Ω headphones)
Maximum Output Level
+6 dBu (unloaded)
Power Output
40 mW RMS
(per channel into 32 Ω headphones)
Mechanical Keys
61 semi-weighted keys with aftertouch
Pads
(16) velocity- and pressure-sensitive pads, RGB-backlit
(8) banks accessible via Pad Bank buttons
Knobs
(4) 360° touch-sensitive Q-Link knobs
(4) Q-Link Knob columns accessible via Q-Link button
(1) 360° encoder for value/data adjustment
Buttons
(44) dedicated function buttons; white-, red-, or green-
backlit
Touch Strip
(1) Multi-function, touch-capacitive control strip
0.8” x 4.4” / 20 x 113 mm (width x hei
g
ht)
Display
7” / 177 mm (diagonal)
Full-color LED-backlit display with touch interface
Memory RAM
4 GB
Internal Storage
32 GB
Expandable via SAT
A
connections
File System
Compatibility
exFAT
(read & write) (recommended)
FAT32
(read & write)
NTFS
(read & write)
EXT4
(read & write)
HFS+
(read only)
Audio Files: AIF/AIFF, FLAC, MP3, OGG, WAV

Akai MPC Live Specifications

General

Built-in display	Yes
Mixer section	-
Product color	Black
Number of drum pads	16
Built-in optical drive	No
USB version	3.2 Gen 1 (3.1 Gen 1)
Audio (L/R) out	2
Headphone outputs	1
USB connector type	USB Type-A, USB Type-B
USB ports quantity	3
Headphone connectivity	3.5 mm
Cables included	USB

Weight and Dimensions

Depth	223 mm
Width	410 mm
Height	67.5 mm
Weight	2721.55 g
