Akai MPC Live User Manual

434
12 all new plugins from AIR include the following:
AIR Channel Strip
This specially-designed plugin combines multiple effects with a fast interface. The EQ section provides a
highpass filter, low and high shelves, and a fully parametric mid-band. For dynamics, the AIR Compressor and
Gate algorithms are perfect for achieving hard-hitting drum sounds.
Tab Parameter Value Range Default Value
EQ Enable Enabled, Bypass Enabled
Gate Enable Enabled, Bypass Enabled
Comp Enable Enabled, Bypass Enabled
Output -Inf – +24.00 dB 0.00 dB
EQ Hi
g
h Shelf Gain -12.0 – +12.0 dB 0.0 dB
Hi
g
h Shelf Freq 1.20 – 20.0 kHz 6.00 kHz
Mid Gain -18.0 – +18.0 dB 0.0 dB
Mid Freq 40.0 Hz – 16.0 kHz 247 Hz
Mid Q 0.40 – 10.00 1.00
Low Shelf Gain -12.0 – +12.0 dB 0.0 dB
Low Shelf Freq 20.0 Hz – 1.00 kHz 100 Hz
HP Filte
r
0 – 1000 Hz 0 Hz
Gate/Comp Gate Thresh -120.0 – 0.0 dB -120.0 dB
Gate Depth 0 – -120.0 dB -120.0 dB
Gate Attack 0.01 – 1000.00 ms 0.18 ms
Gate Release 1.00 – 3000.00 ms 7.40 ms
Comp Thresh 0.0 – -60.0 dB 0.0 dB
Comp Ratio 1.0:1 – 100.0:1 3.9:1
Comp Attack 100 us – 300 ms 5.48 ms
Comp Release 10.0 ms – 4.00 s 200 ms
AIR Compressor
This basic compressor effect changes the dynamic
range of a signal by automatically reducing its gain if it
exceeds a certain level (the threshold).
Parameter Value Range Default Value
Threshold -60.0 – 0 dB -48.0 dB
Ratio 1.0:1 – 100.0:1 3.9:1
Output 0.0 – 30.0 dB 15.0 dB
Mix 0–100% (dry-wet) 100%
Knee 0–100% 50%
A
ttack 100 us – 300 ms 5.48 ms
Release 10.0 ms – 4.00 s 200 ms

Akai MPC Live Specifications

General

Built-in display	Yes
Mixer section	-
Product color	Black
Number of drum pads	16
Built-in optical drive	No
USB version	3.2 Gen 1 (3.1 Gen 1)
Audio (L/R) out	2
Headphone outputs	1
USB connector type	USB Type-A, USB Type-B
USB ports quantity	3
Headphone connectivity	3.5 mm
Cables included	USB

Weight and Dimensions

Depth	223 mm
Width	410 mm
Height	67.5 mm
Weight	2721.55 g
