Introduction Example (R)STP Configuration - Standard VLAN
Software Reference for SwitchBlade x3100 Series Switches (Layer Two Switching)
4-76
4
show stp
--- STP Information ----------------------------------------------------------
Spanning Tree Type...................... RSTP
Instance Name......................... MAIN (0)
Instance State........................ ENABLED
Root Bridge ID Priority................. 32768
Root Bridge ID MAC Address............ 00:0C:25:00:06:AD
Max Age (seconds)..................... 20
Hello Time (seconds).................. 2
Forward Delay (seconds)............... 15
Bridge ID Priority...................... 32768 (priority 32768 mstid 0)
Bridge ID MAC Address................. EC:CD:6D:03:10:CB
Bridge Max Age (seconds).............. 20
Bridge Hello Time (seconds)........... 2
Bridge Forward Delay (seconds)........ 15
Int Role State Cost Prio.Numbe Type
----- ---------- ---------- ---------- ----------- -------------------------
0.0 ROOT FORWARDING 2000 128.321 RSTP
0.20 DESIGNATED FORWARDING 200000 128.341 RSTP
0.21 DESIGNATED FORWARDING 200000 128.342 RSTP
0.22 ALTERNATE DISCARDING 20000 128.343 RSTP
1.2 DESIGNATED FORWARDING 2000 128.387 RSTP
1.3 DESIGNATED FORWARDING 2000 128.388 RSTP
11.0 DESIGNATED FORWARDING 20000 128.1025 RSTP
Reset RSTP to default configuration.
5
set stp default The root port is changed from interface 0.0
back to interface 0.22.
View RSTP configuration
TABLE 4-12 Configuration Procedure for RSTP
Step Command Description/Notes
