EPSR and (R)STP Interaction Introduction
4-151
Software Reference for SwitchBlade x3100 Series Switches (Layer Two Switching)
ADD EPSR VLAN
Description Adds a VLAN to the already existing EPSR domain. The user can add a VLAN as a CON-
TROL or DATA type. The interfaces associated with the EPSR domains should be tagged
members of the CONTROL or DATA vlan being added to that domain.
Syntax
ADD EPSR={ epsrdomain-list } VLAN={ vlanname-list | vid-range } [
TYPE={ CONTROL | DATA } ]
Options The following table gives the range of values for each option that can be specified with
this command and a Default Value (if applicable).
Example
ADD EPSR ALLIED VLAN=1200 TYPE=CONTROL
Option Description Default Value
EPSR The name(s) that has been given to the EPSR
domain(s)
NA
VLAN The VLAN(s) that are being added to the EPSR
configuration.
NA
TYPE CONTROL - A VLAN that carries the EPSR con-
figuration messages.
A CONTROL vlan must be
of UFO type. A CONTROL vlan, once added
to any EPSR domain, cannot be added to any
other domain either as CONTROL or DATA
type
DATA - A VLAN that carries traffic. One or more
VLANs can be configured as DATA VLANs in one
EPSR domain.
A DATA vlan cannot be associ-
ated with two EPSR domains that are part of
the same physical RING network (EPSR
domains having the same interfaces provi-
sioned).
DATA
