Via Objects 0x5F11, 0x5f12, 0x5F13 and 0x5F14 four different Phasing profile can be
created. The Phasing Profile is selected via Control word bits 12 and 13.
Phasing select
Phasing Profile
Bit 13
Bit 12
0
0
1 (0x5F11)
1
1
2 (0x5F12)
0
0
3 (0x5F13)
1
1
4 (0x5F14)
Alternatively the parameters 1125, 1126 and 1127 can be used instead of the Objects.
The 4 data sets of the parameters correspond to the 4 Objects.
Usage of the Objects
will write the parameters in RAM (data set 6…9).
Object
Parameter
0x5F11/1
0x5F12/1
0x5F13/1
0x5F14/1
Phasing 1: Offset
Phasing 2: Offset
Phasing 3: Offset
Phasing 4: Offset
1125.1
1125.2
1125.3
1125.4
Phasing: Offset
0x5F11/2
0x5F12/2
0x5F13/2
0x5F14/2
Phasing 1: Speed
Phasing 2: Speed
Phasing 3: Speed
Phasing 4: Speed
1126.1
1126.2
1126.3
1126.4
Phasing: Speed
0x5F11/3
0x5F12/3
0x5F13/3
0x5F14/3
Phasing 1: Acceleration
Phasing 2: Acceleration
Phasing 3: Acceleration
Phasing 4: Acceleration
1127.1
1127.2
1127.3
1127.4
Phasing: Acceleration
Example:
COB ID
CB
Index
SI
Data
Read Request
601
40
11 5F
01
00 00 00 00
Reply
581
43
11 5F
01
01 00 00 00
Write Access
601
23
11 5F
01
FF 00 00 00
Reply
581
60
11 5F
01
00 00 00 00
CB: Control byte SI: Sub Index All values in hexadecimal without leading 0x
104 CM-CAN ACU 04/13
