12.5.26 0x6078/0 Current actual value
Index
Sub-index
Meaning
Data type
Access
Map
Def.-Val
0x6078
0
Torque actual value
Integer16
ro
Tx
Object 0x6078 Current actual value displays the current actual value (see parameter
R.m.s current 211).
A value of 0x3E8 (=1000) corresponds to the rated motor current (100.0 %). The
rated motor current is set during the commissioning in parameter Rated Current 371.
Example:
COB ID
CB
Index
SI
Data
Read Request
601
40
78 60
00
00 00
Reply
581
4B
78 60
00
00 00
CB: Control byte SI: Sub Index All values in hexadecimal without leading 0x
12.5.27 0x6079/0 DClink circuit voltage
Index
Sub-index
Meaning
Data type
Access
Map
Def.-Val
0x6079
0
DClink circuit voltage
Integer32
ro
Tx
Object 0x6079 DC link circuit voltage displays the actual value of the DC link voltage
in mV (see parameter DC-Link Voltage 222).
A value of 0x0001 86A0 (=100 000) corresponds to 100.000 V (three decimal points).
Example:
COB ID
CB
Index
SI
Data
Read Request
601
40
79 60
00
00 00 00 00
Reply
581
43
79 60
00
CA E8 04 00
CB: Control byte SI: Sub Index All values in hexadecimal without leading 0x
04/13 CM-CAN ACU 135
