BONFIGLIOLI Vectron Active Cube User Manual

12.5.35 0x6091/n Gear ratio
Index
Sub-index
Meaning
Data type
Access
Map
Def.-Val
0x6091
0
Highest sub-index supported
Unsigned8
ro
No
2
1
Motor shaft revolutions
Unsigned32
rw
No
1
2
Driving shaft revolutions
Unsigned32
rw
No
1
Object works in:
• Motion Control:
o All modes
Object doesn’t work in:
• Non motion Control (conf. ≠ x40)
Object 0x6091 gear ratio defines the ratio of motor shaft revolutions to driving shaft
revolutions.
srevolution shaft driving
srevolution shaft motor
0x6091/2
0x6091/1
ratioGear =
1116
1117
Parameter
Parameter
sRevolution ShaftDriving :Box Gear
s
Revolution
Shaft Motor
:Box Gear
Writing to object motor shaft revolutions automatically generates a write command to
parameter Gear Box: Motor Shaft Revolutions 1117
(data set 5, all data sets in RAM
only!).
If object 0x6091/1 was written and then a save parameters command (object 0x1010)
processed, the object value is stored in non volatile memory.
After the next power on of the inverter, the previously set value is
reactivated and
overwrites the setting of Gear Box: Motor shaft revolutions 1117.
Writing to object driving shaft revolutions automatically generates a write command to
parameter Gear Box: Driving Shaft Revolutions 1116 (data set 5, all data sets in
RAM
only!).
If object 0x6091/2 was written and then a save parameters command (object 0x1010)
processed, the object value is stored in non volatile memory.
After the next power on of the inverter, the previously set value is reactivated and
overwrites the setting of parameter Gear Box: Driving Shaft Revolutions 1116.
Alternatively the parameters 1116 and 1117 can be used instead of the Objects.
Object
Parameter
0x6091/1
Motor Shaft revolutions
1117
Gear Box: Motor Shaft Revolutions
0x6091/2
Driving Shaft revolutions
1116
Gear Box: Driving Shaft Revolu-
tions
=
04/13 CM-CAN ACU 143
