12.4.6 0x3005/0 Boolean DeMux
Index
Sub-index
Meaning
Data type
Access
Map
Def.-Val
0x3005
0
Boolean DeMux
Unsigned16
rw
Rx
0
Via object 0x3005 up to 16 boolean values can be written in a compressed manner.
These values are available as sources which can be chosen by the
selection of
832 … 847 Obj 0x3005 Demux Out 1…16 from a parameters choice list.
Obj. 0x3005
Bit no.
Source No.
Source name
0
832
Obj. 0x3005 Demux Out 1
1
833
Obj. 0x3005 Demux Out 2
2
834
Obj. 0x3005 Demux Out 3
3
835
Obj. 0x3005 Demux Out 4
4
836
Obj. 0x3005 Demux Out 5
5
837
Obj. 0x3005 Demux Out 6
6
838
Obj. 0x3005 Demux Out 7
7
839
Obj. 0x3005 Demux Out 8
8
840
Obj. 0x3005 Demux Out 9
9
841
Obj. 0x3005 Demux Out 10
10
842
Obj. 0x3005 Demux Out 11
11
843
Obj. 0x3005 Demux Out 12
12
844
Obj. 0x3005 Demux Out 13
13
845
Obj. 0x3005 Demux Out 14
14
846
Obj. 0x3005 Demux Out 15
15
847
Obj. 0x3005 Demux Out 16
Example:
COB ID
CB
Index
SI
Data
Read Request
601
40
05 30
00
00 00
Reply
581
4B
05 30
00
05 00
Write Access
601
2B
05 30
00
20 00
Reply
581
60
05 30
00
00 00
CB: Control byte SI: Sub Index All values in hexadecimal without leading 0x
