16.4 Warning Messages Application
When the highest bit in the Warning messages is set, a “Warning Message Application” is present.
The Application warning messages are given via parameter Application Warnings 274, bit-coded
according to the following scheme.
Parameter Application Warnings 273
shows the warnings in clear text on the operator panel and
the PC software tool VPlus.
Use Parameter
Application Warnings
274 to access the Application warning codes via Field bus.
Warning Messages
Bit-No.
Bit-No.
Bit-No.
0
0x0001
BELT
- Keilriemen
1
0x0002
SW-LIM CW
– SW limit switch Clockwise
2
0x0004
SW-LIM CCW
– SW limit switch Counterclockwise
3
0x0008
HW-LIM CW
– HW limit switch Clockwise
4
0x0010
HW-LIM CCW
– HW limit switch Counterclockwise
5
0x0020
CONT
– Contouring error
6
0x0040
ENC
– Warning Absolute encoder
7
0x0080
User 1
– User Warning 1
8
0x0100
User 2
– User Warning 2
9
0x0200
(reserviert)
10
0x0400
(reserviert)
11
0x0800
(reserviert)
12
0x1000
(reserviert)
13
0x2000
(reserviert)
14
0x4000
(reserviert)
15
0x8000
(reserviert)
The warnings are described in detail in the operating instructions or the application
manual “Positioning” respectively.
The Warning Bit 6 “Absolute encoder” can be read out via Parameter 1274
in VPlus or
1273 via field bus. The Absolute encoder warnings are described in detail in the Exten-
sion manual EM-ABS-01.
230 CM-CAN ACU 04/13
