12.4.18 0x5F10/0 Gear factor
Index
Sub-index
Meaning
Data type
Access
Map
Def.-Val
0x5F10
0
Highest sub-index supported
Unsigned8
ro
No
3
1
Numerator
Integer16
rw
Rx
1
2
Denominator
Unsigned16
rw
Rx
1
3
Resync on change
Integer16
rw
No
1
Object works in:
• Motion Control:
o Electronic Gear: Slave
o
Table Travel Record
mode
(Electronic Gear operation)
Object doesn’t work in:
• Motion Control:
o Profile Positioning mode
o Velocity mode
o Profile Velocity mode
o Homing mode
o Interpolated mode
o Move away from Limit Switch
• Non motion Control (conf. ≠ x40)
Object 0x5F10 active motion block is available in Electronic Gear: Slave mode in mo-
tion control configurations (P.30 = x40). The Electronic Gear: Slave
mode is activated
by object 0x6060 modes of operation set to -3.
With the Gear factors (numerator and denominator) a multiplier for the master speed
can be set up. The Slave speed results in:


= 

×
 0x5F10/1
 0x5F10/2
Limitation of acceleration when the gear factor is changed is effected via Object
0x5F10/3 Gear Factor: Resync on change . The slave is resynchronized with the ma
s-
ter when the gear factor has changed. This function avoids sudden speed changes.
0x5F10/3 Gear Factor:
Resync on change .
Function
0 -
Off
Resynchronization is switched off.
1 - On
The slave is resynchronized with the master frequency
when the gear factor has changed.
The drive adjusts to the new frequency. The accelera-
tion ramps set in Object 0x6083
Profile Acceleration is
considered.
04/13 CM-CAN ACU 101
