The following sequence of telegrams results:
Server
-ID
-ID
Segment Upload, first and odd segments
Server
-ID
-ID
Segment Upload, second and even segments
-ID
-ID
Segment Upload, last segment
Server
-ID
oder
00 00 00 00 00 00 00
11.3.4.2 Writing Segmented Transfer
The first telegram to write is executed via Command Specifier 0x21. The amount of
entered data bytes in the data area defines the amount of data bytes to be transmi
t-
ted in the following segment transfers. The following segments are controlled via
Command Specifier 0x00 and 0x10 in toggling order until all data were transmitted.
The last segment
contains in the Command specifier (Bit 1…3) the amount of not
used data bytes in the last telegram.
The resulting request and response telegrams are shown in the following sequence.
An example is described in chapter 12.3.1.4.
