14.4.8.1 Example Sequence
To start the Electronic Gear: Slave mode, the correct sequence has to be sent from
the PLC.
1
Control word =
0x0000
Disable voltage
Status word =
0x0050
Switch On Disabled
2
Modes of Operation =
-3
(Electronic Gear: Slave mode)
3
Control word =
0x0006
Shutdown
Status word =
0x0031
Ready to switch on
4
Control word =
0x0007
Switch On
Status word =
0x0033
Switched On
5
Control word =
0xn327
Enable Operation.
Status word =
0xn337
Operation enabled
6a
Control word =
0xn727
Start Electronic Gear without Direct Syn-
chronization
Status word =
0xn327
Operation enabled, Slave not
(yet)coupled, Phasing not finished.
Status word =
0xn337
Operation enabled, Slave not
(yet)coupled, Phasing finished.
Status word =
0xn727
Operation enabled, Slave coupled, Phas-
ing not finished.
Status word =
0xn737
Operation enabled, Slave coupled, Phas-
ing finished.
6b
Control word =
0x005F
Start Electronic Gear with Direct Synchro-
nization
Status word =
See 6a
See 6a
7a
Control word =
0x021F
Start Electronic Gear without Direct Syn-
chronization and Phasing Profile 1
Status word =
See 6a
See 6a
7b
Control word =
0x121F
Start Electronic Gear without Direct Syn-
chronization and Phasing Profile 2
Status word =
See 6a
See 6a
7c
Control word =
0x221F
Start Electronic Gear without Direct Syn-
chronization and Phasing Profile 3
Status word =
See 6a
See 6a
7d
Control word =
0x321F
Start Electronic Gear without Direct Syn-
chronization and Phasing Profile 4
Status word =
See 6a
See 6a
8a
Control word =
0x025F
Start Electronic Gear with Direct Synchro-
nization and Phasing Profile 1
Status word =
See 6a
See 6a
8b
Control word =
0x125F
Start Electronic Gear with Direct Synchro-
nization and Phasing Profile 1
Status word =
See 6a
See 6a
8c
Control word =
0x225F
Start Electronic Gear with Direct Synchro-
nization and Phasing Profile 3
Status word =
See 6a
See 6a
8b
Control word =
0x325F
Start Electronic Gear with Direct Synchro-
nization and Phasing Profile 4
Status word =
See 6a
See 6a
222 CM-CAN ACU 04/13
