15 Parameter list
The parameter list is structured according to the menu branches of the operating unit.
For better clarity, the parameters have been marked with pictograms:
The parameter is available in the four data sets.
The parameter value is set by the SET-UP routine.
This parameter cannot be written when the frequency inverter is in operation.
15.1 Actual values
No.
Description
Unit
Display range
Chapter
Actual values of the frequency inverter
228
Internal Reference Frequency
Hz
-1000.00 ... 1000.00
14.3.3
249
Active Data Set
-
1 ... 4
14
260 Current error - 0 ... 0xFFFF
12.5.2
16.5
270
Warnings
-
0 ... 0xFFFF
16.3
274
Application Warnings
-
0 ... 0xFFFF
16.4
282
Reference Bus Frequency
Hz
-1000.00 ... 1000.00
14.3.3
283
Reference Ramp Frequency
Hz
-1000.00 ... 1000.00
14.3.3
1290
Node State (NMT)
-
0 … 127
11.7
1291
CAN State (physical layer)
-
0 … 4
6
1453
OS SyncSource Act
-
Selection
11.10
Actual values of the frequency inverter
1108
Actual Position u
--2147483647 …
2147483647
12.5.14
1109
Act. Contouring Error u
--2147483647 …
2147483647
12.5.41
The parameters
Current error 260 , Warnings 270
and
Application Warnings 274
are only accessible via the communication channel of objects PPO1 and PPO2. It ca
n-
not be accessed via the VPlus program or the KP500 control unit.
15.2 Parameters
No.
Description
Unit
Display range
Factory setting
Chapter
CAN bus
276
CAN Interface
-
Selection
1 - CM-CAN
9
385
CAN Baud Rate
-
Selection
6 - 250 kBit/s
7
387
CAN Node Number
-
-1 … 127
-1
8
388
CAN Error Behavior
-
Selection
1 - Error
10, 12.5.1
Rated motor parameters
373
No. of Pole Pairs
-
1 ... 24
2
12.5
Bus control
392
State-transition 5
-
Selection
2 - Ramp
14.3.2
412 Local/Remote - Selection
44 - Ctrl. Cont.+KP,
Dir. Cont.+KP
14
Data set change-over
414
Data set selection
-
0 ... 4
0
14
Frequency ramps
420
Acceleration (Clockwise)
Hz/s
0.01 ... 9999.99
5.00
12.5.9
421 Deceleration (Clockwise) Hz/s 0.01 ... 9999.99 5.00
12.5.10,
12.5.11
224 CM-CAN ACU 04/13
