16.3 Warning messages
The various control functions and methods as well as the hardware of the frequency
inverter contain functions that continuously monitor the application. In addition to the
messages documented in the manual, the following warning messages are activated
by the communication module.
The warning messages are given via parameter Warnings 270, bit-
coded according to
the following scheme. The parameter Warnings 270 is mean
t to be read out by PLCs,
parameter Warnings 269
shows the same information with a short text description in
VPlus and Keypad KP500.
Warning messages
Bit no.
Warning code
Meaning
0
0x0001
Warning Ixt
1
0x0002
Warning Short Term - Ixt
2
0x0004
Warning Long Term - Ixt
3
0x0008
Warning Heat sink Temperature Tc
4
0x0010
Warning Inside Temperature Ti
5
0x0020
Warning Limit
6
0x0040
Warning Init
7
0x0080
Warning Motor Temperature
8
0x0100
Warning Mains Failure
9
0x0200
Warning Motor Protective Switch
10
0x0400
Warning Fmax
11
0x0800
Warning Analog Input MFI1A
12
0x1000
Warning Analog Input A2
13
0x2000
Warning System bus
14
0x4000
Warning Udc
15
0x8000
Warning Warning status application 367
The meaning of the individual warnings is described in detail in the operating instruc-
tions.
04/13 CM-CAN ACU 229
