7 Baud rate setting/line lengths
The transmission speed of the CANopen
®
communication module CM-CAN can be set
via the parameter CAN Baud rate 385.
Parameter
Setting
No.
Description
Min.
Max.
Fact. sett.
385
CAN Baud rate
1
8
6
The transmission rate is a function of a variety of application-specific parameters. The
line length of the communication network limits the transmission speed due to the
signal propagation time of the CANopen
®
protocols.
CANopen
®
interface
Operation mode
Function
max. Line length
1 -
10 kBaud
Transmission rate 10 kBaud
5000 meter
2 -
20 kBaud
Transmission rate 20 kBaud
2500 meter
3 -
50 kBaud
Transmission rate 50 kBaud
1000 meter
4 -
100 kBaud
Transmission rate 100 kBaud
500 meter
5 -
125 kBaud
Transmission rate 125 kBaud
500 meter
6 -
250 kBaud
Transmission rate 250 kBaud
250 meter
7 -
500 kBaud
Transmission rate 500 kBaud
100 meter
8 -
1000 kBaud
Transmission rate 1000 kBaud
25 meter
Changing the baud rate causes a restart of the CANopen
®
system (NOT a reset of
the inverter).
8 Setting the node number
The CANopen
®
protocol supports a maximum of 127 nodes in a communication net-
work. Each frequency inverter is assigned a node ID
, which may only exist once in the
system, for its unambiguous identification. The node number is set with
parameter
CAN Node Number 387.
Parameter
Setting
No.
Description
Min.
Max.
Fact. sett.
387
CAN Node Number
-1
127
-1
The factory setting CAN Node Number 387 = -1 means that the CANopen
®
inter-
face has been deactivated.
The value Can Node number 387 = 0 is not allowed and cannot be set.
Changing the node number causes a restart of the CANopen
®
system (NOT a reset
of the inverter).
04/13 CM-CAN ACU 27
