12.4.4 0x3003/0 Digital Out set values
Index
Sub-index
Meaning
Data type
Access
Map
Def.-Val
0x3003
0
Digital Out set values
Unsigned8
rw
Rx
0
Via object 0x3003 there are 5 digital sources available for use with parameters, which
require digital values.
Object 0x3003
Bit
Source no.
Source name
Operation mode
Digital output
0
810
Obj 0x3003 Digout 1
90/190
1
811
Obj 0x3003 Digout 2
91/191
2
812
Obj 0x3003 Digout 3
92/192
3
813
Obj 0x3003 Digout 4
93/193
4
814
Obj 0x3003 Digout 5
94/194
The value of object 0x3003 is limited from 0 to 31.
No.
Object
Min.
Max.
0x3003/0
Digital Out set values
0
31 (= 0x1F)
Digital outputs use these sources as operation mode 90 … 94 Obj 0x3003 DigOut
1 … 5 respectively inverted as 190 ... 194 inv. Obj 0x3003 DigOut 1 … 5
(see e.g.
parameter Op. Mode Digital Output 1 530 ). The mapping of this object
bits to the
outputs is arbitrary.
Example:
Function
Parameter no.
Choice list (excerpt)
Op. Mode Digi-
tal Output 3
532
0 -
OFF
1 -
Ready or Standby Signal
2 -
Run Signal
…
43 -
External Fan
90 -
Obj 0x3003 Digout 1
91 -
Obj 0x3003 Digout 2
92 -
Obj 0x3003 Digout 3
93 -
Obj 0x3003 Digout 4
94 -
Obj 0x3003 Digout 5
…
143 -
inv. External Fan
190 -
inv. Obj 0x3003 Digout 1
191 -
inv. Obj 0x3003 Digout 2
192 -
inv. Obj 0x3003 Digout 3
193 -
inv. Obj 0x3003 Digout 4
194 -
inv. Obj 0x3003 Digout 5
…
The sources can be chosen directly by the selection of 810…814 Obj 0x3003 DigOut
1 … 5 from the parameters choice list. This can be used e.g. for direct setting of Boo
l-
ean inputs.
Example:
COB ID
CB
Index
SI
Data
Read Request
601
40
03 30
00
00
Reply
581
4F
03 30
00
03
Write Access
601
2F
03 30
00
10
Reply
581
60
03 30
00
00
CB: Control byte SI: Sub Index All values in hexadecimal without leading 0x
