CDM-570/570L Satellite Modem with Optional IP Module Revision 12

Front Panel Operation MN/CDM570L.IOM

5–14

5.2.2.1.3.3 (CONFIG: Tx) Code (Code Rate)

Tx Code Rate: 5/16 21/44

1/2 2/3 3/4 7/8 0.95 Unc

IMPORTANT NOTE: All available choices are presented at all times. If an

option is not installed (either Hardware, or FAST) or valid, the ◄ ► arrow keys

will force the cursor to skip past the unavailable choice.

CASE RULES

5/16 Requires BPSK AND Turbo

21/44 Requires BPSK or QPSK/OQPSK AND Turbo

1/2 Valid for BPSK, QPSK and OQPSK

2/3 Requires TCM AND 8-PSK AND RS codec installed

3/4 Valid for QPSK, OQPSK, 8-PSK, 8-QAM and 16-QAM

7/8 Valid for QPSK, OQPSK, 8-PSK, 8-QAM and 16-QAM

0.95 Valid for QPSK, OQPSK, 8-PSK and 8-QAM

Unc (uncoded) Valid only for ‘Uncoded’ in FEC choice
