CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Ethernet IP Module Interface MN/CDM570L.IOM
13–7
13.3.10.1 Combined Working Mode
In order greatly simply the configuration complexity, the working modes operation of modem
have been centralized in the single Working Mode configuration parameter, which in turn offer
the following functional parameters:
Mode Selection Function
Managed Switch
Managed switch with support for VLAN as well as advanced features
such as QoS, Header Compression and Payload Compression.
Primarily intended for operation in a point-to-point topology.
Router-Hub
Hub side router in a Point-to-Multipoint network.
Allows Sat-to-sat
Router-Remote
Remote Router in a Point-to-Multipoint network. Packets from the WAN
are not allowed to be sent to the WAN. No longer requires HDLC
receive addresses to be configured.
Router-Point to Point Point-to-Point router in Point-to-Point configurations.
Vipersat Router-Hub Hub router in a Vipersat Network
Vipersat Router-Hub Expansion Hub Expansion router in a Vipersat Network
Vipersat Router-Remote Remote router in a Vipersat Network
Vipersat Router-Remote Expansion Remote Expansion Router in a Vipersat Network.
The Vipersat “Unit Role” and “Expansion Role” parameters are not read-only.
