CDM-570 Satellite Modem with Optional IP Module Revision 12
Base Modem Web Server Interface MN/CDM570L.IOM
7–5
7.3 HTTP Interface Page Descriptions
The sections that follow detail the web pages accessible via hyperlink from the navigation tabs
illustrated by the splash pages shown in Sect. 7.2.3 and 7.2.3
Each section subsequently defines features common to either the CDM-570 or the CDM-570L
Base Modem HTTP Interfaces (content unique to either the CDM-570 or CDM-570L interface is
noted accordingly):
For: See:
Home Pages Sect. 7.3.1
Admin (Administration) Pages Sect. 7.3.2
Config Mdm (Configure Modem) Pages Sect. 7.3.3
Stats Pages Sect. 7.3.4
ODU (Outdoor Unit) Page Sect. 7.3.5 (CDM-570 only) – summary only
Maint (Maintenance) Page Sect. 7.3.6
7.3.1 Home Pages
Click the Home, Contact, or Support hyperlink to continue.
7.3.1.1 Home | Home
Click the Home tab and/or hyperlink from any location within the Base Modem HTTP Interface
to return back to this top-level page.
Figure 7-3. Satellite Modem Home page (CDM-570L shown)
