CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Front Panel Operation MN/CDM570L.IOM
5–36
Demod: Not Locked
RSL=-64
Press ENTER or CLEAR to return to the previous menu.
5.2.2.2.3 MONITOR: Event-Log (Stored Events)
Stored Events: View
Clear-All (◄ ►,ENTER)
Use the
◄ ► arrow keys to select View or Clear-All, and then press ENTER.
5.2.2.2.3.1 (MONITOR: Stored Events) View
Log23: 30/11/02 10:37:32
Fault - Demod Lock (▲ ▼)
When a fault condition occurs, it is time-stamped and put into the Stored Events Log. This log
can store up to 255 events. Similarly, when the fault condition clears, this is also recorded, as
shown per the following example:
Log240:30/11/97 10:37:35
Clear - Demod Lock (▲ ▼)
Use the
▲ ▼ arrow keys to scroll backwards or forwards through the log entries. Press ENTER
or CLEAR to return to the previous menu.
5.2.2.2.3.2 (MONITOR: Stored Events) Clear-All
Clear all Stored Events?
No Yes (▲ ▼, ENTER)
Use the ▲ ▼ arrow to choose No or Yes, and then press ENTER. If Yes is selected, the event log
is cleared and the previous menu is displayed. However, if faults are present on the modem at this
time, they are re-time-stamped and new log entries are generated.
Note that in accordance with European convention, the date is shown in DAY-
MONTH-YEAR format.
5.2.2.2.4 MONITOR: Stats (Link Statistics)
Link Statistics: View
Clear-All Config(◄ ►,ENT)
Use the
◄ ► arrow keys to select View, Clear-All, or Config, and then press ENTER.
