CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Front Panel Operation MN/CDM570L.IOM
5–9
(CONFIG: Remote Control) Serial: Baudrate
Local M&C Bus Baud Rate:
19200 Baud (▲ ▼,ENTER)
Edit the baud rate of the remote control bus that is connected locally to the M&C computer.
Use the
▲ ▼ arrow keys to change the value. Values of 2400, 4800, 9600,19200, 38400 and
57600 baud are available. Press ENTER when done.
The asynchronous character format is FIXED at 8 data bits, 1 stop bit, no
parity (8-N-1).
5.2.2.1.1.2 (CONFIG:) Remote Control: Ethernet
In Ethernet mode, Serial monitoring is allowed; however, Serial control is not
allowed except for use of the LRS (Local/Remote Status) and FPL (Front Panel
Lockout) commands/queries.
Ethernet Config: Gateway
Address MAC SNMP (◄ ►)
Use the ◄ ► arrow keys to select Gateway, Address, MAC, or SNMP, and then press ENTER.
(CONFIG: Remote Control) Ethernet: Gateway
Ethernet IP Gateway:
192.168.001.002 (◄ ►,▲ ▼)
To edit the modem Ethernet M&C port’s IP Gateway Address: First, use the ◄ ► arrow
keys to select a digit to edit, and then use the ▲ ▼ arrow keys to edit the value of that digit.
Press ENTER when done.
(CONFIG: Remote Control) Ethernet: Address
Ether IP Address/Range:
192.168.001.002/24(◄ ►,▲ ▼)
To edit the modem Ethernet M&C port’s IP Address and Range: First, use the ◄ ► arrow
keys to select a digit to edit, and then use the ▲ ▼ arrow keys to edit the value of that digit.
Press ENTER when done.
(CONFIG: Remote Control) Ethernet: MAC
M&C Port MAC Address:
00-06-B0-00-01-06 (ENTER)
This read-only screen displays the unit MAC Address. Once the MAC Address has been
noted, press ENTER or CLEAR to exit this menu.
To Next Page
