CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Introduction MN/CDM570L.IOM
1–10
current hardware configuration of the modem. A unique FAST Access Code is purchased that
enables configuration of the specific hardware upgrade.
1.3.13 Supporting Hardware and Software
CDM-570L Redundancy
For 1:1 applications the modem is supported by the low-cost external CRS-170A L-band 1:1
Redundancy Switch.
For Hub applications, the CDM-570L is supported by the low-cost external CRS-300 1:N
Redundancy Switch coupled with the CRS-280L Redundancy Switch.
CDM-570 Redundancy
For 1:1 applications the modem is supported by the low-cost external CRS-180 70/140MHz 1:1
Redundancy Switch.
For Hub applications, the CDM-570 is supported by the low-cost external CRS-300 1:N
Redundancy Switch coupled with the CRS-280 IF (70/140 MHz) Switch.
Support Software
The CDM-570/570L is supported by Comtech EF Data’s SatMac (Satellite system Monitor and
Control) Version 4.7 software, a Windows
TM
-based application that provides a ‘point and click’
interface for the complete system of Comtech EF Data equipment (comprising Modems,
Transceivers, and Redundancy Switches).
For more information or to order a free demo disk, please contact Comtech EF Data Customer
Support during normal business hours. SatMac is also available for download from the M&C
Utilities link on Comtech EF Data’s website (http://www.comtechefdata.com/pcutils.asp
).
