CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Appendix L MN/CDM570L.IOM
L–15
L.5 ODU Operations via the CDM-570L IP Module HTTP Interface
L.5.1 ODU-Accessible IP Module HTTP Interface – Overview
As with the CDM-570L Base Modem HTTP Interface, the optional IP Module’s
embedded HTTP Interface provides an easy to use application to configure and
monitor all aspects of a BUC or LNB. For a complete overview of the features
for this interface, see Sect 13.6. IP Module HTTP Interface.
L.5.1.1 IP Module HTTP Interface – Home Page and Menu Tree
Once a web browser is opened and a
valid IP address has been entered,
the CDM-570L IP Module HTTP
Interface “splash” page is displayed:
The options available through this interface are illustrated with the following menu tree. Operations
not specific to the ODU appear dimmed in this diagram and are explicitly defined in Section 13.6.
IP Module HTTP Interface:
Home Admin
Modem
IP Stats Maint
Home Summary Modem Interface Ethernet Unit Info
Contact Mode Utilities Routes Routes Operations
Support Access Status Multicast
QoS*
1
Save
Logoff Features Logs QoS Mode
WAN Reboot
Remote
BUC
QoS Compression
Encryption
LNB
ARP
VLAN
IGMP
Redundancy
