5.2.2.4.9 INFO: Ref (Frequency Reference)
Frequency Reference:
Internal 10 MHz (ENTER)
This screen displays the source of the frequency reference for the CDM-570/570L.
5.2.2.4.10 INFO: ID (Circuit ID)
Circuit ID: (ENTER)
24 CHARACTER TST MESSAGE
This screen displays the user-defined Circuit ID string that is composed via the UTIL: ID
submenu.
5.2.2.4.11 INFO: 1:1 (1:1 Redundancy)
Redundancy State:Standby
Serial 1:1 Link: Active
• On the top line: This screen displays the Redundancy State (1:1 or 1:N) as Online or
Standby
• On the bottom line: The status of the serial link between the two units is indicated as Active
or Idle.
5.2.2.5 SELECT: Save/Load
Save/Load Configuration:
Save Load (◄ ►,ENTER)
This menu branch allows the storing or loading of up to 10 different modem configurations (0
through 9) in the non-volatile memory of the modem. Use the
◄ ► arrow keys to select Save or
Load, and then press ENTER.
5.2.2.5.1 Save/Load Configuration: Save
Use the ▲ ▼ arrow keys to select the location where the current configuration is to be stored,
and then press ENTER. Locations 0 through 9 are available.
Using Location 9 for this example:
If Save is selected and the chosen location is empty, the screen appears as follows:
Save Config to Loc: 9
Empty (▲ ▼)
To Next Page
