CDM-570 Satellite Modem with Optional IP Module Revision 12

Base Modem Web Server Interface MN/CDM570L.IOM

7–17

7.3.5 ODU (Outdoor Unit) Pages

See Appendix K. CDM-570 ODU (CSAT-5060, KST-2000A/B) OPERATION for

complete details on ODU operations via the CDM-570 Base Modem HTTP

Interface.

The ‘ODU’ (Outdoor Unit) tab and its related hyperlinks are available only on the CDM-570 Base

Modem HTTP Interface. They are accessible only when a CSAT-5060 or KST-2000A/B ODU is

configured for operation via FSK for the CDM-570.

7.3.6 Maint (Maintenance) | Unit Info Page

Figure 7-13. Maint (Maintenance) page

Use this page to review a scrollable, read-only status window that provides information about the

currently loaded Bootrom. For Bulk1 and Bulk2, information about all the constituent firmware

blocks that make up the bulk is provided.
