CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Ethernet-based Remote Product Management MN/CDM570L.IOM
6–5
1. For proper SNMP operation, use the CDM-570/570L MIB files with the
associated version of the CDM-570/570L modem M&C and the IP Module
SW. See the CDM-570/570L FW Release Notes for information on the
required FW/SW compatibility.
2. For SNMP access via the Ethernet M&C port, configure the CDM-570/570L
via SELECT: CONFIG Æ REM Æ ETHERNET.
6.4.1 Management Information Base (MIB) Files
MIB files are used for SNMP remote management of a unique device. A MIB file consists of a
tree of nodes called Object Identifiers (OIDs). Each OID provides remote management of a
particular function. These MIB files should be compiled in a user-supplied MIB Browser or
SNMP Network Monitoring System server. The following MIB files are associated with the
CDM-570/570L:
MIB File/Name (where ‘X’
indicates the revision letter)
Description
FW10874-2X.mib
ComtechEFData MIB file
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data products and
consists of only the following OID:
Name: comtechEFData
Type: MODULE-IDENTITY
OID: 1.3.6.1.4.1.6247
Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtechEFData(6247)
Module: ComtechEFData
FW10874-3X.mib
IP Module MIB file
MIB file for the optional IP Module consists of all of the OIDs for management of the
IP functions
FW10874-4X.mib
CDM-570/570L MIB file
MIB file consists of all of the OIDs for management of the CDM-570/570L modem
functions
FW10874-5X.mib
CDM-570/570L Traps MIB file
Trap MIB file is provided for SNMPv1 traps common for base modems.
FW10874-6X.mib
CDM-570L BUC/LNB MIB file
CDM-570L MIB file consists of all of the OIDs for management of the BUC and LNB.
FW10874-7X.mib
CDM-570L L-Band BUC/LNB
Traps MIB file
CDM-570L Trap MIB file is provided for BUC and LNB SNMPv1 traps
FW10874-8X.mib
CSAT-5060 MIB file
MIB file consists of all the OIDs for management of the CSAT-5060 Transceiver
connected to the CDM-570 modem through FSK.
FW10874-9X.mib
KST-2000A/B MIB file
MIB file consists of all the OIDs for management of the KST-2000A/B Transceiver
connected to the CDM-570 modem through FSK.
