If, however, the selected location already contains data, the time and date stamp of the previously
stored configuration displays for identification purposes, as per the following example:
Save Config to Loc: 9
11:10:29 23/12/03 (▲ ▼)
If the selected location does not contain a previously stored configuration, the screen appears as
follows:
Your Configuration has
been Saved to Loc 9 (ENT)
Press ENTER or CLEAR to return to the previous menu.
If, however, the selected location does contain a previously stored configuration, you will be first
prompted to overwrite the location. The screen appears as follows:
Loc 9 Contains Data!
Overwrite? NO YES (◄ ►)
Use the
◄ ► arrow keys to select No or Yes, and then press ENTER. Selecting Yes overwrites the
selected location’s existing configuration.
Once a modem configuration has been properly saved, press ENTER or CLEAR to return to the
previous menu.
5.2.2.5.2 Save/Load Configuration: Load
Use the ▲ ▼ arrow keys to select the location from where the current configuration is to be
loaded, and then press ENTER. Locations 0 through 9 are available.
Using Location 9 for this example:
If Load is selected and a configuration is stored at the chosen location, the time and date stamp of
the previously stored configuration displays for identification purposes, as per the following
example:
Load Config from Loc: 9
11:10:29 23/12/03 (▲ ▼)
If, however, the selected location contains no configuration data, the screen appears as follows:
Load Config from Loc 9
Empty (▲ ▼)
Use the
▲ ▼ arrow keys to select another location from which to load a configuration (e.g.,
Location 8), and then press ENTER. If the newly selected location contains valid data, the
display appears as follows:
To Next Page
Loading...
