Ethernet IP Module Interface MN/CDM570L.IOM
13–2
o Remote software/firmware upgrade via FTP
• Configuration Backup and Restore via FTP
• Event Logging to Capture all IP Module Activity
• Detailed Statistics of IP traffic
• IGMP Support for Multicast
• Static IP Routing for Unicast and Multicast
• Managed Switch Mode with VLAN Support (added in Firmware Ver. 1.5.4)
• Streamline Encapsulation (for Ethernet IP Module V1/MPP-50 FW Ver. 1.6.# and later,
or Ethernet IP Module V2/MPP-70 FW Ver. 2.2.# and later).
13.3.1 10/100BaseT Ethernet Interface
In Router Mode operation, the 10/100BaseT Ethernet Interface is used for routing IP traffic to be
transmitted over the satellite or routed to another device on the local LAN. In Managed Switch
Mode, the Ethernet Interface is used to forward IP and non-IP traffic over the satellite. Local or
remote management of all CDM-570/570L and IP Module functions is also available via Telnet,
HTTP, or SNMP.
13.3.2 Network-Based Management
Use any of the following methods to configure, operate, and monitor the CDM-570/570L Satellite
Modem with Optional IP Module:
User Interface Connection
Modem
Functions
IP Module Functions
Manual
Reference
Front Panel Local - Keypad ALL
IP Address/Subnet
Mask only
Chapter 5
SNMP
Local or remote - Ethernet via
10/100 BaseT Traffic interface
ALL ALL Chapter 6.4
HTTP (Web Server)
Local or remote - Ethernet via
10/100 BaseT Traffic interface
ALL ALL Chapter 13.6
Serial Command
Line Interface (CLI)
Local - Serial RS-232 via
Console Port
ALL ALL Chapter 14
Telnet
Local or remote - Ethernet via
10/100 BaseT Traffic interface
ALL ALL Chapter 14
Serial Remote
Control
Local - Serial RS-232/RS-485
via Remote Control Port
ALL
IP Address/Subnet
Mask only
Appendix D
13.3.3 Remote Software/Firmware Upgrade via FTP
The IP Module uses ‘flash memory’ technology internally. This simplifies firmware updating,
and updates can be obtained over the Internet, through e-mail, or on CD. New firmware can be
