CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Front Panel Operation MN/CDM570L.IOM
5–46
New Config has been
Loaded from Loc 8 (ENT)
Once a modem configuration has been properly loaded, press ENTER or CLEAR to return to the
previous menu.
5.2.2.6 SELECT: Utility
UTIL: Buffer Clock Ref
ID 1:1 VFD Firmware FAST
Use the
◄ ► arrow keys to select Buffer, Clock, Ref, ID, 1:1, VFD, Firmware, or FAST, and
then press ENTER.
5.2.2.6.1 UTIL: Buffer (Buffer Re-center)
Press ENTER to Re-Center
the Receive Buffer
Press ENTER to force re-centering of the Plesiochronous/Doppler buffer.
5.2.2.6.2 UTIL: Clock (Set Real-time Clock)
Edit Real-Time Clock:
12:00:00 24/04/03(◄ ►,▲ ▼)
To edit the time and date settings of the real-time clock: First, use the ◄ ► arrow keys to select
the digit to edit, and then use the ▲ ▼ arrows keys to edit the value of that digit. Press ENTER
when done.
Note that in accordance with European convention, the date is shown in DAY-
MONTH-YEAR format.
5.2.2.6.3 UTIL: Ref (Reference)
Internal Freq Ref:Adjust
Warm-up delay (◄ ►,ENTER)
Use the
◄ ► arrow keys to select Adjust or Warm-up delay, and then press ENTER.
