CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Updating Firmware MN/CDM570L.IOM
4–9
Step Task
9
Transfer the files from the temporary folder on the PC:
Type “put FW-#######*.bin” (where ‘#######’ is the designated image file number, and ‘*’
is the revision letter) to begin the file transfers. It will take several minutes to transfer and
write the files to flash memory.
10 Verify the file transfer:
a) The PC should report that the file transfer has occurred, and the display on the
CLI or Telnet will indicate that the image is being written to flash memory.
b) Terminate the FTP session by typing "bye" and close the DOS window.
c) Confirm that the new file was loaded by using the procedure in Step 1.
11
Change the desired image to boot. By default, the IP Module will boot to the version with
the latest date (Boot to – Latest). “Boot to” can also be set to force the modem to boot up
using either Image #1 or Image #2. The IP Module will then need to be reset (i.e., rebooted
or power cycled) from the serial console, Web Server Interface, or CLI/Telnet for the
firmware update selection to become active:
• To reset from the serial console, use serial remote command ‘FRB=’ (Force
Reboot).
• To reset from the IP Module Web Server Interface, select the Maint | Reboot page,
then click [Yes, Reboot].
• To reset from the CLI/Telnet Main Menu, select Operations and Maintenance [O],
then Reset [R].
If the file transfer is not successful for any reason, do not reset or power
down the CDM-570/570L. Restart the FTP session and repeat Steps 7
through 9.
If the file transfer is still not successful, contact Comtech EF Data Network
Product Support:
Telephone: 480.333.2433
Email: cdmipsupport@comtechefdata.com
4.6 USB Procedure
USB reflash is not available in this firmware release – please consult Comtech
EF Data Customer Support for release schedule.
