CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Front Panel Operation MN/CDM570L.IOM
5–18
(CONFIG: Tx) Output Power Level Mode: AUPC Æ Target-E
b
/N
0
Remote Demod - Target
Min Eb/No:14.9dB (◄ ►,▲ ▼)
To edit the Remote Demod Target E
b
/N
0
: First, use the ◄ ► arrow keys to select a digit to
edit, and then use the
▲ ▼ arrow to edit the value of that digit. The default value is 3.0 dB,
and the upper limit is 14.9 dB. Press ENTER when done.
(CONFIG: Tx) Output Power Level Mode: AUPC Æ Max-Range
Maximum-permitted Power
increase: 1dB (▲▼,ENT)
Use the
▲ ▼ arrow keys to edit the value of maximum permitted increase in power level
(when in AUPC mode), and then press ENTER. The default value is 1dB, and the
upper limit is 9 dB.
(CONFIG: Tx) Output Power Level Mode: AUPC Æ Alarm
Action when max Tx Power
reached: None TxAlarm ◄ ►
Use the
◄ ► arrow keys to set the action that occurs – None or TxAlarm – if the AUPC
causes the maximum output power level to be reached. Press ENTER when done.
(CONFIG: Tx) Output Power Level Mode: AUPC Æ DemodUnlock
Action when Remote Demod
unlocks: Nom-Pwr Max-Pwr
Use the
◄ ► arrow keys to set the action that occurs if the remote demod is unlocked,
and then press ENTER.
Note the following:
Selection Description
Nom-Pwr (Nominal Power) The output level reverts to the nominal power level set under Manual.
Max-Pwr (Maximum Power) The output level changes to the maximum permitted.
5.2.2.1.3.8 (CONFIG: Tx) Scram (Scrambling)
Tx Scrambling:Default-On
IESS-315-On Off (◄ ►,ENT)
Use the
◄ ► arrow keys to select Default-On, IESS-315-On, or Off, and then press ENTER.
