CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Front Panel Operation MN/CDM570L.IOM
5–52
5.2.2.6.10.2 (UTIL: FAST) View
View Options: 03 (▲ ▼)
150W BPSU Not Installed
Use the
▲ ▼ arrow keys to view which FAST options are currently installed or available.
The top line displays the Option Number. The bottom line provides a description for that option,
along with its current operational status (i.e., “Installed” or “Not Installed”). Options
listed as “Not Installed” are available for purchase from Comtech EF Data. The available
options are as follows:
Option Number Option Type Displayed Code Description
01
Hardware
150WBPSU 150 Watt, 48 volt BUC PSU
02 100W BPSU 100 Watt, 24 volt BUC PSU
03 RS Codec Reed-Solomon Codec
04 TPC Codec Turbo Product Codec
05 TPC/LDC Turbo Product Codec/LDC
06 IP Mod_v1 OR IP Mod_v2
IP Traffic Module (where v1 = MPP-50
module, and v2 = MPP-70 module)
07 H/W Exp-1 Future Hardware Expansion 1
08 H/W Exp-2 Future Hardware Expansion 2
09
FAST
2048 kbps 2048 kbps max data rate
10 5000 kbps 5000 kbps max data rate
11 8PSK/8QAM 8-PSK and 8-QAM modulation
12 16-QAM 16-QAM modulation
13 9980 kbps 9980 kbps max data rate
14 Hdr Comp IP Header Compression
15 Data Comp IP Datagram Compression
16 IP QoS IP Quality of Service
17 3xDES IP 3xDES Encryption
18 Vipersat Management by VMS
19 VFS Vipersat File Streamer
20 G703 CEx G.703 Clock Extension
21 G703 Intc G.703 Interface
5.2.2.7 SELECT: ODU Menus (CDM-570 ONLY)
See Appendix K. CDM-570 ODU (CSAT-5060 OR KST-2000A/B) OPERATION for
complete details about this modem-specific menu branch.
Transceiver Control:
Disable Enable(◄ ►,ENTER)
For the CDM-570 only: This menu branch is used to monitor and control a Comtech EF Data
RF Transceiver (CSAT-5060 or KST-2000A/B), if connected.
