Front Panel Operation MN/CDM570L.IOM
5–5
5.2.2 SELECT: (Main) Menu
CDM-570L: CDM-570:
The Select: (Main) menu provides user access to all modem configuration, monitor and control
menu branches.
On the next page, Figure 5-3 illustrates t
he hierarchal structure of the front panel menu tree, from
the SELECT: menu on down.
The table that follows identifies the functional description/overview for each menu branch. Note
that the menu branch selection order differs between the CDM-570L and CDM-570. (For
information purposes, this chapter is ordered per the CDM-570L Main Menu.) Refer to the
chapter sections listed here for detailed information about the menu operations provided therein.
Menu Branch Sect. Description
Config
5.2.2.1 Used to fully configure the modem.
Monitor 5.2.2.2
Used to monitor the alarm status of the modem, to view the log of stored
events, and to display the Receive Parameters screen.
Test 5.2.2.3 Used to invoke one of several test modes (loopbacks, for example).
Info 5.2.2.4
(Information) Used to view information on the modem, without having to
go into configuration screens.
Save/Load (CDM-570L)
Save/Ld (CDM-570)
5.2.2.5 Used to save and to retrieve up to 10 different modem configurations.
Util 5.2.2.6
(Utility) Used to perform miscellaneous functions, such as setting the
Real-time clock, adjusting the display brightness, etc.
ODU
5.2.2.7
(Summary
only)
(Outdoor Unit) On the CDM-570 only: Used to monitor and control a
Comtech EF Data RF Transceiver (CSAT-5060 or KST-2000A/B), if
connected.
See Appendix K. CDM570 ODU (CSAT-5060
OR KST-2000A/B)
OPERATION for full details.
The actual choices displayed in the submenus may vary according to which
FAST options have been enabled. Where a FAST option affects a menu, this
is identified in the descriptive text.
Use the ◄ ► arrow keys to select a menu branch from the choices available for either the
CDM-570L or CDM-570 Main menu, and then press ENTER.
SELECT: Config Monitor
Test Info Save/Load Util
ELECT: Config Test Info
Monitor Save/Ld Util ODU
