CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Front Panel Operation MN/CDM570L.IOM
5–41
5.2.2.4 SELECT: Info
INFO:All Tx Rx Buf Frame
Intfc Rem Msk Ref ID 1:1
The Info menu branch provides access to screens that display information on the modem’s current
configuration. All screens provide information on a read-only basis – the information provided on
these screens may be viewed only – no editing is possible.
Use the
◄ ► arrow keys to select All, Tx, Rx, Buf, Frame, Intfc, Rem, Mask, Red, ID, or 1:1,
and then press ENTER. Typical for all nested Info screens, press ENTER or CLEAR to return
to the SELECT: Info menu.
5.2.2.4.1 INFO: All
All = Start
(Stop, Start) (▲ ▼,ENTER)
This screen set allows review of the modem configuration in its entirety. Use the ▲ ▼ arrow
keys to select between Stop and Start, and then press ENTER. Once a specific configuration
displays, press ENTER to continue through the remaining configuration displays.
To discontinue: Press CLEAR, use the ▲ ▼ arrow keys to select Stop, and then press ENTER.
5.2.2.4.2 INFO: Tx (Transmit)
Tx:1140.000 5000.000 TUR
8P 0.95 S EXT -20.0 ON I
This screen displays the following Transmit information:
Display Line Description
Top Line
• Transmit Frequency and Data Rate
(NOTE: Due to space limitations, the resolution of displayed frequency is limited to 1 kHz,
and data rate to 10 bps)
• FEC Encoder type (VIT = Viterbi, VRS=Viterbi + Reed-Solomon, TCM = Trellis Coded +
Reed-Solomon, TUR = Turbo, UNC = uncoded)
Bottom Line
• Modulation type (Q = QPSK, OQ= OQPSK, B = BPSK, 8P = 8-PSK, 8Q = 8QAM,
16=16-QAM)
• Code Rate (Unc = Uncoded, 2144 = 21/44, then 5/16, 1/2, 2/3, 3/4, 7/8, 0.95)
• Scrambler state (S = Scrambler on, N = Scrambler off, I = IESS-315 On)
• Clocking Mode (INT = internal, EXT = external, LOP = loop, CXE = internal & Clock
Extend TxLock E1 mode, CXT = internal & Clock Extend TxLock T1 mode)
• Output power level
• Transmit output state (ON = on, OF = off, EO= external off, RT= Rx-Tx Inhibit)
• TSI state (I = Transmit Spectral Inversion on, N = off)
