CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Appendix E MN/CDM570L.IOM
E–31
E.5.8.4 Quality of Service (QoS) Statistics Commands and Queries
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction
Code and
Qualifier)
Response to Query
Quality of Service
Statistics Get
N/
A
String of QoS
Stats
Query only.
Displays the QoS queue statistics of all active queues.
nnn|pp|aaaaaaaaaa|bbbbb|cccccccccc|dddddddddd|eeeeeeeeee|fffff|ggggg|h
hhhh|iiii
n – QoS Rule Number
p – Protocol number [Refer to QSR]
a – Sent Packets
b – Pkts per Second
c – Sent Bytes
d – Dropped Packets
e – Dropped Bytes
f – Current Transmit Rate [Kbps]
g – Average Transmit Rate [Kbps]
h – Maximum Transmit Rate [ Kbps]
I – Active Flow count associated with this QoS Queue.
>0001/QST=
0|19| 0| 0| 0| 0| 0| 0| 0| 0| 0chr(13)
1| 0| 0| 0| 0| 0| 0| 0| 0| 0| 0chr(13)
QST!
QST?
QST=sssssssss…
String displaying QoS stats of
all active queues.
\r – CR – 0x0D
\n – Newline – 0x0A
Quality of Service
Stats Clear
QSC=xx
xx = QoS rule
index
xx
–
QoS rule
index for which to
clear stats.
Command only.
Clears the QoS statistics for a specified queue. The command can be issued
only on active/configured queue. To clear default queue stats use ‘0’.
<1/QSC=0 will clear default queue stats
<1/QSC=5 will clear stats of rule-5.
QSC=
QSC!
N/
A
QSC=xx
(see description of argument)
Clear All QoS
Queue Statistics
QSA= QSA=x
1 – Clear all stats
Command only.
Setting QSA=1 will clear all QoS queue statistics. Also clears the default
queue stats.
QSA=
QSA!
N/
A
QSA=x
(see description of argument)
