CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Ethernet IP Module - CLI and Telnet Operation MN/CDM570L.IOM
14–17
14.2.2.10 Payload Compression Refresh Rate
The Payload Compression Refresh Rates determines how many compressed payload packets are
sent before a single full payload packet is sent. Some compressed payload traffic could be lost
during deteriorated satellite link conditions. Sending a full payload packet will allow the return of
the traffic stream. Refresh rates from 1 to 600 can be individually selected. The Refresh Rate can
be decreased for poor satellite link conditions or increased to further reduce overhead.
14.2.2.11 Telnet Timeout
The Telnet timeout determines how many minutes (1-60) of Telnet inactivity before the Telnet
session is automatically terminated by the IP Module.
The IP Module does not allow concurrent access to the menu via Telnet and the
Console port. If a user connects via Telnet, IP Module automatically disables the
Console port for the duration of the Telnet session. All menu pages allow a
Telnet logout to end a Telnet session. Also, the IP Module will automatically end
a Telnet session after a period of inactivity (configurable from 1 to 60 minutes).
14.2.3 Interface Configuration Page
Activate the Interface Configuration page from the Main Menu page.
Figure 14-9. Interface Configuration page
The Interface Configuration page contains the following options/fields:
Selection Entry Description
Ethernet Interface E Displays the Ethernet Interface page.
Satellite/HDLC Interface H Displays the Satellite/HDLC Interface page.
