Admin | Features

This page is available only if you have logged in using the Administrator Name

and Password.

Use this page to configure or obtain a read-only status summary of operational features.

Figure 13-10. Admin | Features page

Features – Standard

Set as Enabled or Disabled (via option button or drop-down menu) the following standard

features:

• Telnet

• Ping Reply

• Managed Switch Multicast Option

• Downlink Route All Available Multicast

• L2 Tx Header Compression

• L2 Rx Header Compression
