CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Ethernet IP Module Interface MN/CDM570L.IOM
13–30
Header Compression – Refresh Rates
In association with enabled L2 Header Compression, this section permits you to enter, via
number of packets, the refresh rates for UPD/RTP1, UDP, Payload, and All Others.
Features – Optional
Set, via drop-down menu, the following optional features (as available) as Enabled or Disabled:
• QoS (Quality of Service)
• STDMA
• IGMP
• L3/L4/L5 Rx Header Compression
• Vipersat
The following optional features have the additional capability to be assigned, from its respective
drop-down menu, on a Per Route basis:
• Tx Payload Compression
• L3/L4/l5 Tx Header Compression
• 3xDES
Once the desired configuration settings have been configured from any of the above sections,
click [Submit] to save those changes.
Feature Availability
As per the ‘Admin | Summary’ page, this read-only section provides information for the
operational features (standard or optional) currently available.
L2 Header Compression applies only when in Managed Switch Mode.
