CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Ethernet IP Module - CLI and Telnet Operation MN/CDM570L.IOM
14–35
Selection Entry Description
VLAN Brouter Next Hop
Address
N On the downlink side, this allows the definition of the MAC of the next hop
router to which all of the Brouted packets must be sent. This permits the
Brouter feature to bypass the need to send an ARP packet for packets that
could potentially have the same IP address.
VLAN Brouter Remote
Mode Enable
R Toggle [Enabled] or [Disabled].
In this mode, IP traffic received from the WAN interface will not be
forwarded back to the WAN interface, even though the route table
matches.
Each remote modem must have Remote Mode enabled
,
indicating this is a distant-end modem.
VLAN Filtering F
Toggle [Enabled] or [Disabled].
Enables/disables bridging for all "Brouted" VLAN destination packets and
routing of non-VLAN traffic.
VLAN ID 1 through 10 0001
thru
4094
The VLAN ID is a 12-bit field in the Ethernet packet that contains the IEEE-
802.1Q tag. Assign a numeric ID in the range from 0001 to 4094.
• VLAN ID 0001 is reserved and used for normal switch
operation.
• A maximum of 10 VLAN ID matches are supported.
Unused VLAN ID match fields must be set to values
that DO NOT match any network VLAN IDs.
