CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Ethernet IP Module - CLI and Telnet Operation MN/CDM570L.IOM
14–40
Selection Entry Description
Tx Modulation M
Sets transmit modulation type
1 – BPSK
2 – QPSK
3 – OQPSK
4 – 8-PSK
5 – 16-QAM
6 – 8-QAM
Tx Spectrum Inversion U
1 – Normal
2 – Inverted
Tx Data Inversion I
1 – Normal
2 – Inverted
Tx Scrambling B
1 – Off
2 – On-Default
3 – On-IESS-315
Tx Output Power P
Valid ranges are from 0.0 to 40.0 dBm (minus sign assumed)
Tx Carrier C
1 – OFF
2 – ON
3 – Rx-Tx Inhibit (turns off the transmitter if the Rx is not locked)
NOTE: In a 1:1 Redundant system, the standby modem will display
[External Control].
Tx Clock Source
[Internal]
