CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Appendix D MN/CDM570L.IOM
D–17
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction Code
and Qualifier)
Response to
Query
Rx Signal Level N/
A
4 bytes Query Only.
Unit returns the value of the Rx signal level, in dBm, between –5 and –99 dBm, in
the form ccxx, where:
cc = code (GT=Greater Than; LT=Less Than, == is ‘equal to’)
xx = value (the ‘-‘ sign is implied)
Examples:
RSL=LT99 (Rx signal level is less than -99 dBm)
RSL===41 (Rx signal level is equal to -41 dBm)
N/
A
RSL?
RSL=ccxx
(see description
of arguments)
Rx Symbol Rate N/
A
8 bytes Query only.
Rx Symbol rate, in ksymbols/sec, between 4.8 ksps and 3.00 Msps Resolution = 1
sps.
Example: RSR=2047.999 (2047.999 ksymbols/sec)
N/
A
RSR?
RSR=xxxx.xxx
(see Description of
Arguments)
Rx Demod
Acquisition Sweep
Width
RSW= 3 bytes Command or Query.
Rx ± acquisition sweep range of demodulator, in kHz, ranging from ± 1 to
± 32 kHz (rates < 625 ksym/second) or
± 1 to ± 200 kHz (rates >= 625 ksym/second) CDM-570L only
Example: RSW=009 (selects ± 9 kHz)
RSW=
RSW?
RSW*
RSW#
RSW?
RSW=xxx
(see Description of
Arguments)
