CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Appendix D MN/CDM570L.IOM
D–19
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction Code
and Qualifier)
Response to
Query
Clear All Stored
Statistics
CAS= None Command only.
Forces the software to clear the software statistics log.
Note: This command takes no arguments.
Example: CAS=
CAS=
G.703 Clock
Extension
CEX 2 byte Command or Query.
G.703 Clock Extension in the form ab, where:
a=G.703 Clock Extension Mode (0=None; 1=TxLock; 2=RxEnable)
b=G.703 Clock Extension Interface (0=T1; 1=E1Bal; 2=E1Unbal)
Example: CEX=12 (Sets Tx Lock to E1 Unbalanced)
Notes:
1. Not all CEX modes are valid all the time.
2. For argument a:
When Data Interface (ITF) is set to be G.703, Clock Extension Mode is
automatically set to be 0=None. Reply: ITF+
When Tx Clock (TCK) is changed from Internal to Non-Internal, Clock
Extension Mode will be automatically changed to 0=None if it was 1=TxLock.
(see Description of
Arguments)
Circuit ID String CID= 24 bytes Command or Query.
Sets or queries the user-defined Circuit ID string, which is a fixed length of 24
characters.
Valid characters include: [Space] ( ) * + – , . / 0 thru 9 and A thru Z
CID=
CID=xxxxxxxxxxxxx
xxxxxxxxxxx
(see Description of
Arguments)
Configuration Load CLD= 1 byte Command only.
Causes the CDM570L to retrieve a previously stored modem configuration from
Configuration Memory location defined by the one-byte argument (0-9).
Example: CLD=4 (retrieve modem configuration from location 4)
CLD=
Configuration Save CST= 1 byte Command only.
Causes the CDM570L to store the current modem configuration in Configuration
Memory location defined by the one-byte argument (0- 9).
Example: CST=4 (store the current configuration in location 4)
CST=
