CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Appendix D MN/CDM570L.IOM
D–21
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction Code
and Qualifier)
Response to
Query
Equipment ID N/A 11 bytes Query only.
Unit returns information concerning the equipment identification, and the option
field, in the form abbbcdefghi; where:
a = Turbo option:
0 = None,
1 = Turbo
bbb defines the modem model number:
CDM-570 = 570, CDM-570L = 571
c = Expansion slot:
0 = None
1 = Reed-Solomon codec installed
d = Data Rate Option:
0 = Base (512 kbps)
1 = up to 2048 kbps
2 = up to 5000 kbps
3 = up to 9980 kbps
e = Higher-order modulation:
0 = None
1 = 8-PSK/8-QAM
2 = 16QAM
3 = 8-PSK/8-QAM and 16QAM
f = IP Module:
0 = None
1 = IP Mod_v1
2 = IP Mod_v2
g = BUC option:
0 = None
1 = 100 Watt
2 = 150 Watt
h = G.703 Clock Extension:
0 = None
1 = Installed
i = G.703 Line Interface
0 = None
1 = Installed
Example: EID=1571013111x means Turbo, CDM-570L, no RS codec, up to 2048bps,
8-PSK/8-QAM and 16-QAM, IP Module installed, 100 Watt BUC supply installed, G.703
Clock Extension option installed
N/
