CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Appendix D MN/CDM570L.IOM
D–30
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction Code
and Qualifier)
Response to
Query
Global
Configuration
MGC= 115 bytes, with
numerical entries,
fixed values and
delimiters
Command or Query.
Global Configuration of CDM570L, in the form shown in the Response to Query
column, where:
MGC=
MGC?
MGC*
MGC#
MGC?
MGC?n
MGC=abcdddd.ddd
defghhhh.hhhijkk.kl
mnoppp.ppqqqqqqq
qAAAA.AAAABCD
EEEE.EEEFGHIIIJJ
.JKLLLLLLLLMNO
OOOPQQQQQQQ
QQQQQRSTTTTT
TTT
(see Description of
Arguments)
Where n=0 to 9
Returns the MGC
portion of 1 of 10
stored
configurations
(see Description of
Arguments)
a = Unit Interface Type
b = T1 Line build-out
c = Unit Framing mode
dddd.dddd = Tx Frequency
e = Tx FEC Type
f = Tx Modulation type
g = Tx FEC Rate
hhhh.hhh = Tx Data Rate
i = Tx Spectrum Inversion
j = Tx Scrambler State
kk.k = Tx Power Level
l = Tx Clock Source
m = Tx Data Invert
n = Tx Carrier State
o = AUPC Enable
ppp.pp = AUPC parameter setup
q = Warm-up delay
rr = G.703 Clock Extension
sssss = expansion bytes
AAAA.AAAA = Rx Frequency
B = Rx FEC Type
C = Rx Modulation Type
D= Rx FEC Rate
EEEE.EEE = Rx Data Rate
F = Rx Spectrum Inversion
G = Rx Descrambler state
H = Rx Data Invert
III = Rx Sweep Width
JJ.J = Eb/No Alarm Point
K = Rx Buffer Size
LLLLLLLL = expansion bytes
M = External Reference Frequency
N = EDMAC Framing Mode
OOOO = EDMAC Slave Address
P = Unit test Mode (Read only)
QQQQQQQQQQQQ = Unit Alarm Mask
same as ITF
same as LBO
same as FRM
same as TFQ
same as TFT
same as TMD
same as TCR
same as TDR
same as TSI
same as TSC
same as TPL
same as TCK
same as TDI
same as TXO
same as AUP
same as APP
same as WUD
same as CEX
same as RFQ
same as RFT
same as RMD
same as RCR
same as RDR
same as RSI
same as RDS
same as RDI
same as RSW
same as EBA
same as RBS
same as ERF
same as EFM
same as ESA
same as TST
same as MSK
